Name: Maple Systems HMI5121P
SKU: 512925

Product Details ＋

Product Attribute	Attribute Value
Backlighting	LED Backlight
CPU Speed	800 MHz
Display Colors	16.2M Color
Display Resolution	1024 x 768 Pixels
Display Size	12.1 Inch Display
HMI Type	Touch Screen HMI
IP Rating	IP66
Memory	256 MB
Mounting Type	Chassis Mount ; Panel Mount
Number of Ports	5 Port
Processor Type	32-bit RISC
Resolution, Display	1024 × 768
Series
Size, Screen	12.1 in.
Supply Voltage	24VDC VDC
Technology	TFT LCD Display
Voltage Rating	24 VDC

Overview

Maple Systems Advanced HMI Series | HMI5121P — Modern Touchscreens, Intuitive Software and Functionality:

The HMI5121P is a high-resolution touchscreen interface with an aluminum enclosure to cut down on interference from external EMF noise. Its built-in VNC server allows for remote communication to the HMI via computer, smart phone, or tablet. This unit is programmed using EZwarePlus software

The Advanced HMI series offers the best value in today’s HMI marketplace with benefits including modern touchscreens, intuitive software, and great functionality. Enjoy enhanced features, trusted performance, affordable pricing, and unparalleled support to meet your most demanding automation needs.

Features:

12.1” HMI | Aluminum Enclosure | Ethernet

1024 x 768 Pixel Resolution

Ethernet

2 Serial Ports

1 CANbus Port

Series Features:

4.3" to 15" models

Easy-to-use configuration software

Class I, Division 2 available

Wi-Fi option available

IP65/IP66/NEMA 4X, CE, and RoHS certified

Aluminum enclosures available

MQTT, OPC UA, & EasyAccess 2.0
